Splined Yoke 07 – Push Pin Type
The Splined Yoke 07 – Push Pin Type is a precision-machined PTO shaft end yoke featuring a push pin mechanism with compact design optimised for tight driveline spaces. Engineered from forged alloy steel with splined bore connection, it provides a secure, high-torque interface between the PTO shaft and universal joint assembly. Available in multiple series to fit standard agricultural and industrial drivelines, this yoke is CNC-machined, heat-treated, and surface-coated for continuous field operation. Supplied by Ever-power with ISO 9001:2015 quality assurance and global shipping.
Splined Yoke 07 Compact Push Pin – Space-Saving Splined PTO Yoke
Compact push pin | Shortest profile | B/D/G/C/E sub-types | Tight installations
The Ever-power Splined Yoke 07 is our shortest-profile push pin yoke, purpose-built for installations where every millimetre of driveline length counts. Despite its compact footprint, it provides full rated torque through precision spline engagement and hardened wear surfaces. Offered in the complete B/D/G/C/E sub-type range, it accommodates all major spline standards.
🔧 Technical Specifications
| Series | A (mm) | B (mm) | C (mm) | E (mm) | F (Spline) |
|---|---|---|---|---|---|
| 1.007B | 22 | 54 | varies | varies | 1 3/8"Z6 |
| 2.007B | 23.8 | 61.3 | varies | varies | 1 3/8"Z6 |
| 3.007B | 27 | 70 | varies | varies | 1 3/8"Z6 |
| 5.007B | 30.2 | 80 | varies | varies | 1 3/8"Z6 |
| 6.007B | 30.2 | 92 | varies | varies | 1 3/8"Z6 |
| 7.007B | 30.2 | 106.5 | varies | varies | 1 3/8"Z6 |
| 8.007B | 35 | 106.5 | varies | varies | 1 3/8"Z6 |
⭐ Key Features & Benefits
🔒
Shortest Push Pin Profile
10–15 mm shorter than standard push pin yokes — the ultimate compact option.
🔧
Full Sub-Type Range
B, D, G, C, E variants cover Z6, Z21, 8-32, and 1 3/4" splines.
💪
Same Forging Quality
Identical C45 forging, heat treatment, and surface coating as larger yokes.
⚙️
Tight-Space Solution
Designed for drivelines with minimal clearance between tractor PTO and implement input shaft.
🔄 Compatibility Information
Engineered for compact tractor-to-implement interfaces with restricted driveline space. The full B/D/G/C/E sub-type range ensures fit on virtually any splined PTO shaft. Compatible with Walterscheid, Bondioli & Pavesi, Comer, and Ever-power shafts. Commonly used on mid-mounted mowers, compact utility tractors, and implements with close-coupled gearboxes where the standard 01 or 05 yoke would be too long.
📚 Selection Guide
Step 1: Measure the available space between your tractor PTO stub and the implement gearbox input.
Step 2: If the gap is under 100 mm, the compact 07 is likely your best option.
Step 3: Identify your spline pattern to select the correct sub-type letter.
Step 4: Cross-reference bore dimensions in the table and confirm cross kit compatibility.
🌾 Typical Application Scenarios
⚙️ Mid-Mounted Mowers
Belly-mount mowers on compact tractors with extremely limited PTO clearance.
💾 Compact Utility Tractors
Sub-compact and CUT models where PTO stub length is minimal.
🌿 Close-Coupled Gearboxes
Implements with gearbox input shafts positioned very close to the tractor PTO output.
🌾 Greenhouse Equipment
Small-frame indoor growing equipment where overall driveline length must be minimised.
🛠️ Installation & Usage Guide
Measure the available clearance and confirm the 07 yoke will fit before removing the old yoke.
Depress the push pin and slide the compact yoke onto the splined shaft.
Confirm the pin clicks into the shaft groove — listen for the audible snap.
Install the cross kit, noting that some compact installations may require a short-body cross kit.
Grease all fittings and check that the yoke does not foul on any adjacent components during rotation.
Run at low speed and verify clearance throughout the full range of driveline oscillation.
❓ Frequently Asked Questions
⭐ Customer Reviews
★★★★★
The 07 solved our clearance problem on a mid-mount mower deck on our Kubota M-series. Nothing else would fit.
Owen P. — 🇦🇺 Australia
★★★★☆
Good compact yoke. Quality is consistent with the rest of the Ever-power range. Would appreciate even shorter options for extreme cases.
Kai S. — 🇩🇪 Germany
★★★★★
Parfait! Our greenhouse tiller driveline had only 85 mm of space — the 07 fit perfectly with room to spare.
Mathilde V. — 🇫🇷 France
★★★★★
We use the 07 exclusively on our compact tractor implement range. Saves valuable driveline length on every unit.
Prakash R. — 🇮🇳 India
★★★★★
Compact and well-made. Dropped right into a tight space on our JD 1025R utility tractor.
Kevin M. — 🇺🇸 United States
📈 Our Product vs. Low-Quality Alternatives
| Feature | Ever-power Yoke | Low-Quality Alternative |
|---|---|---|
| Overall Length | ✔ Shortest in push pin family | ✘ Standard length |
| Spline Options | ✔ 5 sub-types (B/D/G/C/E) | ✘ Single sub-type |
| Clearance Gained | ✔ 10–15 mm saved | ✘ No space optimisation |
| Material | ✔ Forged C45 steel | ✘ Cast iron |
| Surface | ✔ Zinc-plated | ✘ Bare metal |
| Quality | ✔ ISO 9001:2015 | ✘ No certification |
🔗 Related Products & Accessories
Short-Body Cross Kits
Compact U-joints for space-restricted drivelines
01 Series Yokes
Standard-length push pin alternative
PTO Safety Shields
Compact guards for close-coupled drivelines
Compact PTO Shafts
Short-length assembled driveline packages
Telescopic Tubes
Adjustable-length profile tubes
🏆 Certifications & Standards
🏆
ISO 9001:2015
Quality management system certified by accredited body
🛡️
Material Test Reports
EN 10204 3.1 mill certificates for every steel batch
✅
CE Compliance
Meets European machinery safety directives
🔎
100% Inspection
Every yoke dimensionally verified before shipment
🏭 Why Choose Ever-power?
We are Ever-power, and the 07 compact push pin yoke was born from customer feedback requesting a shorter yoke for tight installations. We optimised every dimension while maintaining full rated torque. 20+ years, ISO 9001:2015, 50+ countries.
