Weld on Sprockets and Hubs-Meeting Diverse Industrial Demands
Our weld on sprockets and hubs provide reliable solutions for industrial chain drive systems. The unique design of Weld on sprockets and hubs makes it easy to install and maintain. Through the welding process, weldable sprockets can be firmly fixed on the hub or axle, providing excellent stability and anti-vibration performance. Our weld on sprocket hub is precisely machined to ensure a perfect match with the chain, reduce wear and extend service life. These characteristics make our weld-on-chain sprockets an ideal choice for industrial applications. The following is a detailed introduction to our product classification, covering a variety of models and tooth combinations to meet different application requirements.
Weld on Sprocket Models
We offer a variety of models of weldable sprockets. Including 35 weld on sprockets and hubs, 40 weld on sprockets and hubs, 50 weld on sprockets and hubs, 60 weld on sprockets and hubs, 80 weld on sprockets and hubs and 100 weld on sprockets and hubs. Each model is made of high-strength materials to ensure durability and precise chain meshing. Whether you need small sprockets or heavy weld on chain sprockets, we can provide suitable solutions.
| Model | Pitch | Teeth | Hub Series |
| 35 Weld on Sprockets | 3/8″ Pitch | 15-96 | V,W |
| 40 Weld on Sprockets | 1/2″ Pitch | 12-90 | V,W,X,XX |
| 50 Weld on Sprockets | 5/8″ Pitch | 10-96 | V,W,X,XX |
| 60 Weld on Sprockets | 3/4″ Pitch | 9-96 | V,W,X,XX |
| 80 Weld on Sprockets | 1″ Pitch | 9-60 | W,X,XX |
| 100 Weld on Sprockets | 1-1/4″ Pitch | 10-36 | X,Y |
| Hub No. | Chain No. | d Min. |
d Max. |
OD | HD | L | B | C | App.WL. (Lbs.) | A |
| V | 35-60 | 0.5 | 0.875 | 1.438 | 1.125 | 1.188 | 0.438 | 0.75 | 0.32 | 1-1/8 |
| W | 35-80 | 0.5 | 1.25 | 1.813 | 1.625 | 1.438 | 0.438 | 1 | 0.64 | 1-5/8 |
| X | 40-100 | 0.5 | 1.5 | 2.5 | 2 | 1.438 | 0.438 | 1 | 1.42 | 2 |
| XX | 40-100 | 1 | 1.625 | 3 | 2 | 1.5 | 0.438 | 1.063 | 2.2 | 2 |
| Y | 100 | 1 | 2 | 3.75 | 2.75 | 1.875 | 0.688 | 1.188 | 3.92 | 2-3/4 |
Flexible Selection of Weld-On Sprocket Teeth
Our weld on sprocket teeth design supports a variety of tooth number options, ranging from 9 teeth to 96 teeth, to meet the requirements of different transmission ratios and speeds. Whether it is a low-speed high-torque application or a high-speed light-load scenario, you can find the appropriate weld on sprocket. The selection of the number of teeth for different models of sprockets ensures flexibility and compatibility, making your equipment operate more efficiently.
Why Choose Our Welded Sprockets and Hubs?
We are committed to providing high-quality weld on sprockets and hubs to meet the diverse needs of our customers. All products undergo strict quality control to ensure dimensional accuracy and performance stability. From 35 weld on sprockets and hubs to 100 weld on sprockets and hubs, our product line covers a wide range of industrial scenarios. Furthermore, we offer customization services to design weld on sprocket teeth and hub structures based on your specific needs, contributing to the success of your project. Contact us now!
