SSA Corrosion Resistant Bearing Inserts
For SSA Corrosion Resistant Bearing Inserts, review the complete mounted interface: shaft bore, inner-ring width, outer-ring form and housing seat, then the series-specific locking shaft connection. The product construction is corrosion-resistant insert construction.
Measure from stable machine datums instead of from worn edges or old paint marks. On base-mounted units, the shaft centre and foot-hole locations usually control fit. On flanged units, the bolt pattern and plate opening become more important. Take-up and cartridge arrangements have their own locating dimensions. The drawing should therefore be read according to the mounting form, not as a generic list of numbers.
MOQ: 50 pcs. Minimum order value USD 1,500; mixed orders and trial quantities welcome.
Mounting Pattern Control
Mounting-geometry buying notes
For SSA Corrosion Resistant Bearing Inserts, review the complete mounted interface: shaft bore, inner-ring width, outer-ring form and housing seat, then the series-specific locking shaft connection. The product construction is corrosion-resistant insert construction.
This product family is commonly reviewed for wet, cleaning-intensive or chemically exposed machinery requiring corrosion-resistant insert construction. Actual load, speed, cleaning and contamination conditions should be stated for the ordered position.
Representative
SSA205
Mounting
Narrow inner ring
Locking
Eccentric collar
Representative bore
25 mm
D
52 mm
B
22 mm
Mounting Pattern Control
A mounted bearing can have the correct bore and still be unusable if its fixing pattern does not match the machine. For procurement, bolt centres, centre height and housing envelope are often approval dimensions rather than secondary drawing details.
Measure from stable machine datums instead of from worn edges or old paint marks. On base-mounted units, the shaft centre and foot-hole locations usually control fit. On flanged units, the bolt pattern and plate opening become more important. Take-up and cartridge arrangements have their own locating dimensions. The drawing should therefore be read according to the mounting form, not as a generic list of numbers.
When a frame has elongated holes or field modifications, document them. Pulling a new housing into position with the fixing bolts can twist the support or move the shaft away from its intended line. It is better to resolve the machine interface first and allow the bearing unit to seat naturally against the mounting surface.
Store the confirmed interface dimensions with the product reference after a successful replacement. This makes the next purchase easier and helps distinguish similar models whose main difference is hidden in the mounting geometry.
Bolt-pattern drawing review
Use the drawing to compare shaft bore, inner-ring width, outer-ring form and housing seat. Read the printed values rather than scaling the illustration; for modified equipment, send current machine measurements with the enquiry.
Technical Specifications & Drawing
| Representative bore | 25 mm |
|---|---|
| D | 52 mm |
| B | 22 mm |
| C | 15 mm |
| Series | SSA200 |
| Load / Housing Strength Reference | |
| Catalogue dynamic load (205 size) | 14.03 kN |
| Catalogue static load (205 size) | 8.05 kN |
Applications
Food Equipment
SSA205 can be considered for food equipment where its narrow inner ring geometry matches the machine. Check the machine-side interface shown in the drawing before final model approval.
Chemical & Wet Areas
For chemical & wet areas, the eccentric collar arrangement changes installation access and shaft retention. Confirm that detail before standardising the spare.
Washdown Conveyors
In washdown conveyors service, use the construction of SSA205 only where the actual moisture, contamination and cleaning conditions match the selected product family.
