SSUEFB-A All Stainless Steel Flange Bracket Bearing Units
SSUEFB-A All Stainless Steel Flange bracket bearing units is a flange bracket bearing units using all-stainless housed construction; this version uses concentric locking collar. For fit approval, check bracket outline, bolt locations and shaft offset.
Look at the direction from which a technician will approach the fixing bolts and locking hardware. A compact housing is not necessarily easy to maintain if the wrench swing is blocked or if the collar faces a permanent frame member. On crowded equipment, even a small change in housing outline can decide whether replacement requires removing several unrelated parts.
MOQ: 50 pcs. Minimum order value USD 1,500; mixed orders and trial quantities welcome.
Maintenance Access in Tight Spaces
Service-access buying notes
SSUEFB-A All Stainless Steel Flange bracket bearing units is a flange bracket bearing units using all-stainless housed construction; this version uses concentric locking collar. For fit approval, check bracket outline, bolt locations and shaft offset.
The surrounding use case is typically food, beverage, pharmaceutical and chemical-process equipment using complete stainless mounted supports, but the final choice still depends on the actual machine position and service conditions.
Representative
SSUEFB205A
Mounting
Flange bracket, A style
Locking
Concentric collar
Representative bore
25 mm
Housing material
SUS 304
Set screw
SUS 304
Maintenance Access in Tight Spaces
Bearing supports are often selected while the machine is open and easy to reach, then serviced years later after guards, drives, ducts or product-contact parts surround them. Access therefore belongs in the selection conversation from the start.
Look at the direction from which a technician will approach the fixing bolts and locking hardware. A compact housing is not necessarily easy to maintain if the wrench swing is blocked or if the collar faces a permanent frame member. On crowded equipment, even a small change in housing outline can decide whether replacement requires removing several unrelated parts.
Photograph the wider installation, not only the bearing close-up. That image helps buyers and application engineers understand why one mounting form is preferred. It also gives future maintenance teams a record of how the support sat before dismantling, including guard position and clearance to adjacent components.
Where possible, orient service features toward the maintenance side without altering the intended mechanical installation. After a successful job, note any special access sequence in the maintenance record so the next changeout can be planned with the correct tools and time allowance.
Technical Specifications & Drawing
| Representative bore | 25 mm |
|---|---|
| Representative model | SSUEFB205A |
| Mounting form | Flange bracket, A style |
| Locking | Concentric collar |
| Housing material | SUS 304 |
| Set screw | SUS 304 |
| Retainer | SUS 201 |
| Slinger & frame | SUS 304 |
| Inner & outer rings | SUS 440 |
| Balls | SUS 440 |
| Grease nipple | SUS 304 |
| Operating temperature | -20 C to 120 C |
Service-clearance drawing check
Use the drawing to compare bracket outline, bolt locations and shaft offset. Read the printed values rather than scaling the illustration; for modified equipment, send current machine measurements with the enquiry.
Applications
Food & Beverage
SSUEFB205A can be considered for food & beverage where its flange bracket, a style geometry matches the machine. Bracket hole pattern and offset influence how the bearing sits against the support plate.
Pharmaceutical Equipment
For pharmaceutical equipment, the concentric collar arrangement changes installation access and shaft retention. Confirm that detail before standardising the spare.
Washdown Packaging Lines
In washdown packaging lines service, use the construction of SSUEFB205A only where the actual moisture, contamination and cleaning conditions match the selected product family.
