SSUCP-A All Stainless Steel Pillow Block Bearing Units
Compare mounting style, shaft locking, bore range and installation envelope before selecting the alternative.
SSUCP205ESB All Stainless Steel Pillow Block Bearing | European Solid Base | 25 mm Bore
Buyers evaluating SSUCP205ESB All Stainless Steel Pillow Block Bearing | European Solid Base | 25 mm Bore should treat it as a pillow block bearing units rather than a bore-only bearing reference. Its construction is all-stainless housed construction, with setscrew locking on the shaft.
Use the complete approved reference from quotation through receiving. If the old label is damaged, do not invent the missing characters from appearance. Combine the readable part of the code with bore measurement, mounting dimensions and photos of the shaft-locking area. This produces a more reliable cross-reference than guessing a suffix because the housing “looks the same.”
MOQ: 50 pcs. Minimum order value USD 1,500; mixed orders and trial quantities welcome.
Full-Code and Suffix Discipline
Code-control buying notes
Buyers evaluating SSUCP205ESB All Stainless Steel Pillow Block Bearing | European Solid Base | 25 mm Bore should treat it as a pillow block bearing units rather than a bore-only bearing reference. Its construction is all-stainless housed construction, with setscrew locking on the shaft.
Applications include food, beverage, pharmaceutical and chemical-process equipment using complete stainless mounted supports. Treat that as context only; dimensions and environment at the real bearing point control the final selection.
Representative
SSUCP205ESB
Mounting
Solid-base pillow block
Locking
Setscrew
Representative bore
25 mm
Housing material
SUS 304
Set screw
SUS 304
Technical Specifications & Drawing
| Representative bore | 25 mm |
|---|---|
| Representative model | SSUCP205ESB |
| Mounting form | Solid-base pillow block |
| Locking | Setscrew |
| Housing material | SUS 304 |
| Set screw | SUS 304 |
| Retainer | SUS 201 |
| Slinger & frame | SUS 304 |
| Inner & outer rings | SUS 440 |
| Balls | SUS 440 |
| Grease nipple | SUS 304 |
| Operating temperature | -20 C to 120 C |
| H | 36.5 mm |
| L | 140 mm |
| J | 105 mm |
| A | 38 mm |
| N | 13 mm |
| N1 | 19 mm |
| H1 | 16.5 mm |
| H0 | 70 mm |
| B | 34.1 mm |
| S | 14.3 mm |
| Bolt size | M10 |
| Weight | 0.95 kg |
| Load / Housing Strength Reference | |
| Recommended set-screw torque for SUC204-206 | 3.9 N.m |
Full-Code and Suffix Discipline
Industrial bearing families often contain several versions whose visible shape is almost identical. A suffix can represent locking, sealing, housing detail or another configuration change that is easy to lose when purchase documents use only the broad family name.
Use the complete approved reference from quotation through receiving. If the old label is damaged, do not invent the missing characters from appearance. Combine the readable part of the code with bore measurement, mounting dimensions and photos of the shaft-locking area. This produces a more reliable cross-reference than guessing a suffix because the housing “looks the same.”
Receiving inspection should compare the delivered configuration with the purchase description before the machine is dismantled. Finding a code discrepancy at the warehouse is inconvenient; finding it after the old support has been removed is much more disruptive.
After the first verified installation, update the maintenance system with the exact reference that worked. This creates a controlled trail for future orders and helps inventory teams keep nearby variants separated.
Suffix and drawing confirmation
Use the drawing to compare base bolt spacing, centre height and foot length. Read the printed values rather than scaling the illustration; for modified equipment, send current machine measurements with the enquiry.
Applications
Food & Beverage
SSUCP205ESB can be considered for food & beverage where its solid-base pillow block geometry matches the machine. Base footprint and shaft-centre height are the first fit checks on existing frames.
Pharmaceutical Equipment
For pharmaceutical equipment, the setscrew arrangement changes installation access and shaft retention. Confirm that detail before standardising the spare.
Washdown Packaging Lines
In washdown packaging lines service, use the construction of SSUCP205ESB only where the actual moisture, contamination and cleaning conditions match the selected product family.
Related Products
SSUEPA-A All Stainless Steel Pillow Block Bearing Units
Compare mounting style, shaft locking, bore range and installation envelope before selecting the alternative.
SSUCPA-A All Stainless Steel Pillow Block Bearing Units
Compare mounting style, shaft locking, bore range and installation envelope before selecting the alternative.
Full-code RFQ
Send the complete visible code, all suffix characters, photos and measured interface dimensions.
Buyers evaluating SSUCP205ESB All Stainless Steel Pillow Block Bearing | European Solid Base | 25 mm Bore should treat it as a pillow block bearing units rather than a bore-only bearing reference. Its construction is all-stainless housed construction, with setscrew locking on the shaft.
Use the complete approved reference from quotation through receiving. If the old label is damaged, do not invent the missing characters from appearance. Combine the readable part of the code with bore measurement, mounting dimensions and photos of the shaft-locking area. This produces a more reliable cross-reference than guessing a suffix because the housing “looks the same.”
MOQ: 50 pcs. Minimum order value USD 1,500; mixed orders and trial quantities welcome.
